Scala

Sprout Conservatory with dormer and hipped pent roof

Winter in the garden! Despite snow and freezing sub-zero temperatures in the middle of the garden, in a cozy atmosphere at room temperature: a unique feeling of living that can only be achieved with a winter garden made of wood and aluminum. This beautiful dormer winter garden with a hipped pent roof and all-round ribbon bars offers, even in adverse weather conditions in the cold season, cozy and visually appealing living space, which is also very stylishly furnished. The double-leaf sliding door in the large facade facing the garden is already making you want to go back to the somewhat warmer season of the year ...

Due to the expansion of the former terrace door and window combination, this north-facing winter garden is open wide to the core building. Triple energy-saving glass (north side = only energy losses, no solar energy gains through the glass envelope!) And a perfect heating system (floor duct heating directly on the glass surfaces) ensure that this winter garden can be used as a unique living space 365 days a year.

The pictures were kindly sent to us by the satisfied winter garden owners.





Project details

Object number 25
Location 40489 Düsseldorf
Line Scala
Dimensions
Base area approx. 8.00 x 3.50 m
Design
Special shape
Wooden profile Country house
Wood painting Natural shade
Aluminum profile Semicircular
Aluminum coating Marble brown
Glazing
Triple energy-saving glass, also as self-cleaning and sun protection glass!
Shading
No shading, as it is north-facing. The client has installed curtains on the inside as privacy screens.



Ventilation
On the one hand via the "normal" window and door elements, on the other hand via low-lying metering fans as supply air and two sliding roof windows as high exhaust air.
Control
Standard control for the two exhaust air windows
Special equipment
Triple energy-saving glass with sun protection and self-cleaning function Sprout bars Starry sky lighting in the rafters High security level on all windows and doors Insect protection
Particularities
Connection to house facade with facing wall. In the area of the house connection, the clinker brick facade was removed and doubled up so that it could be connected properly
